Linear Cup Filler Sealer



Product Video

Product Description

TECHNICAL DETAILS

MODEL NO. CUP-800

Suitable for -: Water Cups/Juice Cups

Cup Dia -: 40-95mm

Filling Range -: 50ml-500ml

Filler Type -: Gravimetric

Product Hopper -: 50Lit.

Sealing Type -: Heat Seal Pre-cut Foil Sealer

Indexer -: Geneva

Motor Drive -: 1HP

Heater -: 2KW

Track -: Double

Cup Feeding -: Automatic

Foil Feeding -: Automatic

Power Source -:  220V 50Hz

Power Supply -: 4KW

Contact Parts -: Stainless Steel 316 Grade

Covers -: Stainless Steel

Feature -: No Cup-No Foil

Machine Weight -: 800Kg

Machine Dimension (Wooden Case) -: 2400mmLx1200mmWx 1800mmH

Production Capacity -: 3000 Cups Per Hour


Technical APPLICATION

Cup filling machine is Linear Cup Filling Machine for packaged drinking water, water cup filling sealing, Ice cream cup filling, Yogurt cup filling, Honey, Curd, Buttermilk filling ,Shrikhand in PVC, Plastic cups. Cup filling machine is suitable for Filling & Lid Sealing of cups. Cup filling machine is suitable for Filling & Lid Sealing of cups. Linear Cup Filling Machine with 2 Track operation Automatic cup pickup from stacker hopper Automatic Single head timer based pump filler unit. Single Head foil pick-up & Sealing unit with automatic ejection system. This machine is also known as curd cup filling machine, juice cup filling machine, water cup filling machine, filling sealing machine for cups, yogurt cup filling machine, juice cup filler etc.

Product Unit Type -: 1 SET
